36470 Vision 12 GB 1 800x600

IPC Vision Swimming Pool Enclosure

The shape of this high line model was inspired by the low enclosure Corona.

Full Description

VISION offers full height. If you have enough space around pool you can put furniture inside the enclosure and create great leisure space for you and your family.

Technical parameters

  • Width of enclosure:4,00 – 6,00 m
  • Length of enclosure:6,4 - 14,9 m
  • Height of enclosure:2,29 - 2,78 m
  • Number of segments:3 - 7

Profile surfacing:

Silver
elox C-0 (silver)RAL 9006
White
white RAL 9010RAL 9010
Beige
beige RAL 1015RAL 1015
Anthracite
anthracite DB 703DB 703
Brown
brown - antiqueantique

Polycarbonate:

jkompaktní, tl. 4 mm, průhledný, s UV stabilizací, U=5,4 W/m²K compact, transparent 4 mm, with both-sides UV protection,
U=5,4 W/m² K

Guide rails:

guide rails in the full length of an enclosure
PROGRES - výška 15 mm

PROGRES - height 15 mm, surface - natural elox or beige RAL 1015

  • the front face inner, fixed made from polycarbonate and aluminium profiles
  • 1 door according to the client´s request
  • draft seal on faces up to the height of 150mm
  • locking system of segments PROGRES
36469 Vision 11 GB 1 800x600642 vision 03 CZ 800x600643 vision 04 CZ 800x600644 vision 05 CZ 800x600639 vision 09 H 800x600640 vision 01 H 800x600641 vision 02 H 800x600645 vision 07 H 800x600
MaterialAluminium, Polycarbonate
Products categoriesPools, Spas, Domes , Enclosures
